YD series (IP54) Variable pole multi speed three-phase asynchronous motor

Y2 series (lP54) three-phase asynchronous motor is the latast ganeration of three-phase asynchronous motor daveloped and designed bufanalizing the davanced experiancas from interational developend counties.Various properties have reached the intermational advancedstandard in 1990, The performing standards are conformed to JB/T8680-1998《Y2 series (lP54) three-phase asynchronous motor's technical conditions (Machine base number 63-355》. For Y2 series (lP54) three-phase asynchronous motor, the frame number is 63-355 total 15 frame numbers, the electrode reach 2,4,6,8, Powerfrom 0.12 to 315KW. Totaly 117 specifications. At present, we produced 104 specifications, from frame number 63 to 315. The number of electrode range include 2,4,6,8, and power range from 0.12 to 200KW.

YE3 series (IP55) three-phase asynchronous motor is the latest generation of three-phase asynchronous motor products developed and designed by the advanced experience of my country and internatio;trialized countries. Various performance indicators have reached the interational advanced level, lmplement the standard GB/T 28575-2020《YE3 series three-phase asynchronous motor technicat conditions (frame size 63-355)》. For YE3 series (lP55) three-phase asynchronous motor, the framee number is 63~355 total 15 frame numbers, the electrode reach 2.4.6.8 Power from 0.12 to 315KW, Totaly 117 specifications. At present, we produced 104 specifications, from frame number 63 to 315. The number of electrode range include 2,4,6,8, and power range from 0.12 to 200KW.

YE4 series (IP55) three-phase asynchronous motor is the latest generation of three-phase asynchronous motor products developed and designed by the advanced experience of my country and internatio;trialized countries. Various performance indicators have reached the interational advanced level, lmplement the standard JB/T 13299-2017《YE4 series(IP55) three-phase asynchronous motor technicat conditions (frame size 80-450》. For YE4 series (lP55) three-phase asynchronous motor, the framee number is 80-450 total 15 frame numbers, the electrode reach 2.4.6.8 Power from 0.12 to 1000KW, Totaly 131 specifications. At present, we produced 104 specifications, from frame number 63 to 315. The number of electrode range include 2,4,6,8, and power range from 0.12 to 200KW.

YS series (lP54) smal power three-phase asynchronous motor has an important position in the industry, agricuture whare motor machine is necessary. This series motor has small physical volume, light weltht and beautiful apperance. t is made according to JB/T(1009-2016) 《YS seres three-phase asynchronous motor's technical conditionas》. Our factory produce YS50 and YS56 two frame, motors have 2&4 electrodes totally 8 specifications.

YVF2 series (IP54) frequency-variable speed-regulation three-phase asynchronous motor is the latest unily design in our country, which is derived from Y2 series (IP54). It not only looks beautihul and dignified, but also has low noise and weak vibration. it has wide scope regulate and it is so steady that has no class, This motor has independent and well ventlated cooling system, and can run at low speed over a long time. It is matched with all transducer, have the fast dynamic responding with vector control mode, no torque wave at low speed and no resonance. This series motor frame number is from 80 to 355, total 13 frame numbers and 30 specifications. At present, our factory produce motor at the frame number from 80 to 280, totaly 11 frame numbers and 23 speclfications. This series motor is made according to the JB/T7118-2014 《The technical condlitions for YVF2 series (lP54) frequency-varlable speed-regulation three-phase asynchronous motor》 . We can also produce YVF,EJ seres frequency-varable speed-regulation electromagnetic brake three-phase asynchronous motor.

The Y2EJ series (IE3 IP54) electromagnetic brake three-phase asynchronous motor is a derivative series of Y2 series (IP54) three-phase asynchronous motors. There are a total of 13 machine base sizes ranging from 63~280, with power ranging from 0.12KW to 55KW and pole numbers of 2, 4, 6, and 8, totaling 72 specifications. . The power level, installation size, insulation level, working mode, cooling method, and usage conditions of Y2EJ series (IE3 IP54) electromagnetic brake three-phase asynchronous motors are the same as the corresponding specifications of Y2 series. Implement Q/XL 01-2021 《Technical Conditions for Y2EJ Series (IP54) Electromagnetic Braking Three phase Asynchronous Motors》. . Rated voltage of electromagnetic brake: DC 99V for motor frame sizes 63-100 and DC 170V for motor frame sizes 112-280. The Y2EJ series electric motor is suitable for spindle transmission and auxiliary transmission in various machinery that require fast stopping, accurate positioning, reciprocating operation, frequent starting, and prevention of sliding. Such as lifting machinery, transportation machinery, packaging machinery, printing machinery, food machinery, construction machinery, woodworking machinery, deceleration machinery, metallurgical machinery, forging machinery, etc.

1. The YBX3 series High-Efficiency Flameproof Three-Phase Asynchronous Motor is a derivative series of the Y2 series (IP54) three-phase asynchronous motor in China, and is an updated product of the YB series explosion-proof three-phase asynchronous motor. It has the international advanced level of the 2025s. This series of motors has a beautiful and elegant appearance, a higher protection level than the YB series, and is safer and more reliable to use. Simultaneously, the starting performance is better, and the noise and vibration are lower than those of the YB series. Suitable for use in underground coal mines (non mining working faces) and factories containing explosive gas mixtures. 2. The YBX3 series high efficiency explosion-proof three-phase asynchronous motor strictly follows the standard JB/T12628-2016 《Technical Conditions for YB3 Series Explosion proof Three phase Asynchronous Motors》and has obtained an explosion-proof certificate to organize the production of a full series of 15 machine base numbers from 63-355, with power ranging from 0.12 to 315KW and 117 specifications. Our factory currently produces 13 machine base sizes ranging from 63-280, with a total of 82 specifications of power ranging from 0.12-90KW.
